Optima XPN Ultracentrifuge
The Optima™ XPN is the premier ultracentrifuge. With networking capability and customizable security and tracking features to ensure chain of custody and compliance, the Optima XPN offers multi-layered BioSafety* features for a safe and productive work environment.
- Equipped with the innovative eXpert simulation software
- Available in 100k, 90k, and 80k RPM configurations
- Compatible with extensive rotor and labware options
- Backed by unparalleled service program options
Optima XPN Features
Optimize protocols before running
Quickly perform common calculations and conversions with proprietary software to optimize protocols, save time, and save samples.
Receive diagnostic alerts via email
Remote monitoring and control enables you to start, stop, and monitor from your computer, smart phone, or tablet.
Track detail usage history
Security and tracking features manage your rotor life by serial number. Password protection and electronic signatures help you maintain chain of custody and compliance.
Enhanced Safety
- Dynamic Rotor Inertia Check (DRIC)
- Rotor overspeed disc
- Real and simulated testing
- BioSafe optional dual PALL® Pharmaceutical Grade Sterilizing Filters
Optima XPN Product Specifications
| BioSafe | Yes |
| Acceleration | 10 acceleration profiles |
| Deceleration | 11 deceleration profiles |
| Timed Run | 999 hrs, 59 mins (including hold runs) |
| Max Capacity Volume Range | - 1500 mL |
| Temperature Control | ± 0.5 °C of set temperature |
| Temperature Range(s) | Ambient temperature range: 10° to 35°C, Set temperature range: 0 to 40°C in 1°C increments |
| Display | Full-color LCD touch screen |
| Item Specifications Referenced | B10051 |
Explore Optima XPN Models
Related Parts for Optima XPN
VTi 50.1 Vertical Rotor Package
Purpose-built for Optima Series ultracentrifuges, the VTi 50.1 rotor helps you produce more in less time with rapid density gradient separations. Its short pathlength enables faster run times at high resolution, while the durable rotor structure enables higher density applications without de-rating speed.
Type 100 Ti Fixed-Angle Rotor
Type 100 Ti Rotor, Fixed Angle (26 deg angle), Titanium. For use in instruments classified: RS. Major Applications: Rapid separation of plasmid DNA and rapid differential centrifugation of small particles.
Type 90 Ti Fixed-Angle Titanium Rotor
Type 90 Ti Rotor Assembly with 3 each 839347 O-rings, 3 each 876089 O-rings, and 2 each 355539 Overspeed Disks. For use in instruments classified: HRS
Type 70.1 Ti Fixed-Angle Titanium Rotor
For use in instruments classified: H R S. Major Applications: Differential centrifugation of subcellular particles.
Type 70 Ti Fixed-Angle Titanium Rotor
For use in instruments classified: HRS; Major Applications: Differential centrifugation of subcellular particles.
Type 50.4 Ti Fixed-Angle Titanium Rotor
Type 50.4 Ti Rotor Assembly. For use in instruments classified: H R S; Part Number Description 870138; 2 O-ring for Rotor Lid 854519; 2 O-ring for Rotor Handle 330336; 1 extra Overspeed Disk, 50,000 rpm.
Type 50.2 Ti Fixed-Angle Rotor, 50.000 rpm, 302.000 x g, 12 x 39 mL
Type 50.2 Ti rotor assembly with 3 each 834301 O-rings, 3 each 854519 O-rings, and 2 each 330336 overspeed disks.
Type 45 Ti Fixed-Angle Titanium Rotor
Major applications: Differential centrifugation of large volumes of subcellular fractions and viruses.
Type 42.2 Ti Fixed-Angle Titanium Rotor Package
Type 42.2 Ti Rotor Package. For use in instruments classified: H R S; Includes: Part Number Description 342303; Cellulose Propionate Tubes (bag of 100 each) 330329. Overspeed Disk, 42,000 rpm 332688. Vise Assembly 343008. Spanner Wrench 878446. Forceps 306812; Spinkote Lubricant
335148. Vacuum Grease.
Note: Originally this rotor was intended for small-sample lipoprotein applications and was called the LP 42 Ti. However, it has become a popular choice for processing a variety of microsamples, and the name has been changed to the Type 42.2 Ti to reflect its more general use.
Type 25 Fixed-Angle Rotor
Type 25 Rotor Assembly Includes:
Part Number Description 11757. 3 O-ring for Rotor Handle. 3 O-ring for Rotor Body
332688; 2 Overspeed Disks, 25,000 rpm
Type 19 Fixed-Angle Aluminum Rotor
Type 19 Rotor Assembly, Fixed Angle Rotor, Aluminum. For use in instruments classified: H R S; Major applications: Differential centrifugation of large volumes of viruses and large subcellular particles.
