Avanti J-26S XP Non-IVD Centrifuge, 50 Hz, 230 V
Product No:B14536
Redesigned to provide even more versatility and safety. Built upon standard-setting performance, including high speed, low heat output, imbalance tolerance and low noise, the J-26S XP’s vast range of separations only continues to grow. Above and beyond its BioSafety systems, this centrifuge has a more impact-resistant lid, full containment barrier and automatic rotor identification. Its ergonomic design--with lower instrument height and hands-free door operation--remains unchanged. The J-265 XP can process six liters of fermentor output in less than 10 minutes, deliver a subcellular fraction at 82,000 x g and run 24 microplates at a time. It automatically detects which rotor is installed and prevents the rotor from running above its maximum-rated speed, and enables quicker, quieter, more energy-efficient runs with better temperature control. The exclusive high-torque, switched reluctance (SR) drive shortens cycle times.
Resources + Tools
Product Specifications
| Platform | Avanti |
| Maximum Speed | 26,000 rpm |
| Maximum g-Force | 81800 x g |
| BioSafe | Yes |
| Acceleration | Maximum or Slow |
| Deceleration | Maximum, slow, or off |
| Timed Run | 1 minute-3 hours; Continuous Hold |
| Max Capacity Volume Range | 1 - 6 L |
| Refrigeration System | Non-CFC, non-ozone depleting refrigerant |
| Temperature Range(s) | 10°C - 40°C in 1 degree increments |
| Rotor ID | Automatic |
| Zonal Capability | Yes |
| Pollution Degree | 2 |
| Environmental Conditions | -10°C to 40°C in 1° increments |
| Material(s) | Steel, Plastic |
| Finish | Powder Coat Paint |
| Weight | 290 kg(639.3 lb) |
| Width | 71 cm(28 in) |
| Depth | 86.0, 102.0 with air direviter extending cm(86.0, 102.0 with air direviter extending in) |
| Height | 86 cm (149 cm with door open) |
| Clearances | 7.6 cm (sides) & 16 cm (rear) |
| Humidity Restrictions | < 95% (non-condensing) |
| Power Requirements | 230 VAC, 50 Hz |
Related Products or Parts
JA-12 Fixed-Angle Aluminum Rotor, Biosafety Lid- 12 x 50 mL, 12,000 rpm, 23,200 x g
JA-12 Fixed-Angle Rotor with Dual-Locking Biosafety Lid, Aluminum; Major applications: Pelleting cells, bacteria, or subcellular fractions; phase separations; binding studies. For use in Avanti J Series and J2 Series centrifuges.
JA-14.50 Fixed-Angle Aluminum Rotor, Biosafe, 16 x 50 mL conical, 14,000 rpm, 35,000 x g
16 x 50 ml conical rotor , 14.000 rpm, 35.000 x g
JA-14.50 Fixed-Angle Aluminum Rotor, 16 x 50 mL conical, 14,000 rpm, 35,000 x g
JA-14.50 Fixed-Angle Rotor, Aluminum; Major applications: Lightweight rotor for pelleting and density gradient separations. Separate Proteins, lysate/tissue homogenates, nucleid acids, cells, viruses and blood. For use in Avanti J Series centrifuges.
JA-25.15 Fixed-Angle Rotor, Aluminum, 24 x 15 mL, 25,000 rpm, 74,200 x g
JA-25.15 Fixed-Angle Rotor with Biosafety Lid, Aluminum.
Major applications: Harvesting bacteria, processing tissue homogenates, subcellular particulates, routine pelleting such as precipitates and phase separations.
For use in Avanti J Series centrifuges (except Avanti J-E) and J2 Series centrifuges.
JA-25.15 Fixed-Angle Aluminum Rotor- 24 x 15 mL, 25,000 rpm, 74,200 x g
JA-25.15 Fixed-Angle Rotor with Single Lock Lid, Aluminum. Major applications: Harvesting bacteria, processing tissue homogenates, subcellular particulates, routine pelleting such as precipitates and phase separations. For use in Avanti J Series centrifuges (except Avanti J-E) and J2 Series centrifuges.
JA-25.50 Fixed-Angle Rotor- Aluminum, 8 x 50 mL, 25,000 rpm, 75,600 x g
JA-25.50 Fixed-Angle Rotor with Single Lock Lid, Aluminum. Major applications: Harvesting bacteria, processing tissue homogenates, subcellular particulates, routine pelleting such as precipitates and phase separations. For use in Avanti J Series and J2 Series centrifuges.
JA-25.50 Fixed-Angle Aluminum Rotor, Biosafety Lid- 8 x 50 mL, 25,000 rpm, 75,600 x g
JA-25.50 Fixed-Angle Rotor with Biosafety Lid, Aluminum. Major applications: Harvesting bacteria, processing tissue homogenates, subcellular particulates, routine pelleting such as precipitates and phase separations. For use in Avanti J Series and J2 Series centrifuges.
JA-30.50 Ti Fixed-Angle Titanium Rotor, Biosafety Lid- 8 x 50 mL, 30,000 rpm, 108,860 x g
JA-30.50 Ti Fixed-Angle Rotor with Biosafety Lid, Titanium. Major applications: Harvesting bacteria, processing tissue homogenates, subcellular particulates, routine pelleting such as precipitates and phase separations. For use in Avanti J Series centrifuges (except Avanti J-E and J-HC) and J2 Series centrifuges.
DISCOVER THE NEW 3D EXPERIENCE
JA-30.50 Ti Fixed-Angle Titanium Rotor, Single Lock Lid- 8 x 50 mL, 30,000 rpm, 108,860 x g
JA-30.50 Ti Fixed-Angle Rotor with Single Lock Lid, Titanium. Major applications: Harvesting bacteria, processing tissue homogenates, subcellular particulates, routine pelleting such as precipitates and phase separations. For use in Avanti J Series centrifuges (except Avanti J-E and J-HC) and J2 Series centrifuges.
DISCOVER THE NEW 3D EXPERIENCE
J-LITE®JLA-16.250 Fixed-Angle Aluminum Rotor, Single Lock- 6x250mL, 16,000 rpm, 38,400 x g
Major applications: General purpose, large-volume and multitube processing. Lightweight alternative to conventional 6x 250 rotors; empty rotor weight is 10.3 kg (22.7 lb). For use in Avanti J Series and J2 Series centrifuges.
JA-14 Fixed-Angle Aluminum Rotor, Biosafety Lid- 6 x 250 mL, 14,000 rpm, 30,100 x g
JA-14 Fixed-Angle Rotor, Aluminum; Major applications: General-purpose, large-volume and multi-tube processing. Adapters permit use of up to 30 each 15-mL tubes and up to 72 each 3-mL tubes. For use in Avanti® J Series and J2 Series centrifuges.
JA-18 Fixed-Angle Rotor, Aluminum, 10 x 100 mL, 18,000 rpm, 47,900 x g
JA-18 Fixed-Angle Rotor with Biosafety Lid, Aluminum;
Major applications: High-force, large-volume. Pelleting bacteria, cell membranes, and subcellular organelles.
For use in Avanti J Series and J2 Series centrifuges.
