MET ONE 6015P Remote with Pump (Ethernet Interface, AC Power)
Product No:2088615-PF-EA
The MET ONE 6015P adds serial communication and an integrated relative humidity and temperature port. This port enables the use of an optional probe that includes RH/Temp data along with the particle count data stream to further simplify installation and increase the information your monitoring system provides.
The MET ONE 6000P series remote airborne particle counter offers accurate and reliable continuous particle monitoring. With a sensitivity range of 0.5 to 10 μm, the MET ONE 6000P series is designed to meet the specific needs of cleanroom operations within the pharmaceutical, semiconductor, hard disk drive and flat panel display industries. With an array of industry leading features and simplified installation options, the MET ONE 6000P is easy to integrate with any facility monitoring system. These features also reduce downtime for instrument removal and reinstallation during routine calibration and preventative maintenance cycles. Built with Long Life Laser technology, the MET ONE 6000P offers enhanced diagnostic features that reduce troubleshooting time and related downtime costs.
Product Specifications
| Platform | APC Instruments |
| Performance | ISO 21501-4 unit-to-unit accuracy & reproducibility |
| Industry Standards | ISO 21501-4 , ISO 14644-1:2015, FCC, CE |
| Light Source | Long Life Laser™ Diode |
| Particle Size Analysis Range | 0.5 - 10 μm |
| Flow Rate | 28.32 L per minute |
| Coincidence Loss | 10% at 20,000,000 particles/m³ |
| Sample Volume | 10 µm |
| Throughput | 28.32 L per minute |
| Interfaces & Protocols | Ethernet with Modbus TCP protocol |
| Data Storage | 1,000 samples (oldest records overwritten when buffer is full) |
| Threshold Setting | 0.5 µm |
| Pump Type | Air vacuum, rated for continuous use |
| Zero Count | ISO 21501-4 & JIS B 9921 (1 count or less in 5 min; 95% UCL) |
| Count Alarms, Display & Cycles | User-defined alarm counts displayed via LED on box or remote LED |
| Environmental Conditions | Indoor Environment |
| Temperature Range | Operating temperature range: 10°C to 32°C, Storage temperature range: -40 to +70°C |
| Humidity Restrictions | 80% (non-condensing) |
| Power Requirements | 100-240 VAC, 50/60 Hz, 0.4 A Max |
| Software | Integrates with various software platforms for facility monitoring |
| Operating Modes | Automated or remote sampling |
| Autoclavable | No |
| Nonpyrogenic | Yes |
| Weight | 4.6 kg(10.1 lb) |
| Width | 17.2 cm(6.8 in) |
| Depth | 31.8 cm(12.5 in) |
| Height | 11.5 cm(4.5 in) |
| Color | Silver |
| Package Quantity | 1 |
